Side Tilt Carriages - There are 4 sizings of hook type tine carriages rated by the blade carriage lifting capability. Hook type blade carriages have been consistent.
Class I carriages are rated for loads up to 2000 lbs. The carriage bar spacing for Class I is 13 inches. Class II carriages are rated for cargo as much as 5,550 lbs. Their carriage bar spacing is sixteen inches. Class III carriages are rated for cargo up to 10,000 lbs. The carriage bar spacing for this particular class is twenty inches. Class IV carriages are rated for loads as much as 15,500 lbs. The carriage bar spacing used for this capacity is twenty five inches.
Pin mounted blades differ by the amount of offset between the blade and the blade eye. Different makers will vary the carriages for pin type forks. Carriage capacity would be established by the carriage pin size and by the tine size.
